Victron MultiPlus 5kVA 48V inverter charger

VM-48/5000/70-100

£1,505.84 £1,807.01 including VAT

Out of stock

Weight 30 kg
Dimensions 444 × 328 × 240 mm
DC Voltage

48v

Volt-Amperes

5000

Continuous Rating (25 °C)

4500W

Surge Rating

10000W

DC Voltage Input

48v

Charger Output

70A

Transfer Relay Rating

100A

Certification

G83/2, G59/3-1

AC Presentation

Single phase

Warranty length

5 Years

  • Two AC Outputs*. The main output has no-break functionality to take over supply in event of mains failure or when generator is disconnected. The second output is live only when grid or generator is connected.
  • Parallel operation. Up to 6 Multiplus units can be connected in parallel to achieve higher power output.
  • Three phase capability.
  • Lithium ion battery compatible.
  • PowerControl. A maximum generator or grid current can be set to avoid overloading the supply.
  • PowerAssist. Allows power to be taken from the battery to support the generator or grid and power peak loads.
  • Four stage battery charging.
  • 12 & 24 V models include a 4A trickle charge output for an engine or generator starter battery.
  • Easy system configuration. Either using integrated DIP switches or with a PC and VE.Net
  • 5 years warranty
SKU VM-48/5000/70-100 Categories: , Tags: ,
